Qualified Coating Services (QCS) has the coating expertise, state-of-the-art equipment, and high quality standards you expect from an FAA approved coating services company. QCS specializes in the application of aluminum slurry coatings for the aerospace, industrial gas turbine, automotive, and oil & gas industries. All coatings applied by QCS are chrome-free, REACH-compliant, environmentally-friendly and have been designed to replace legacy hazardous coatings in use today.

PAG provides MRO and Supply Chain Solutions for Fixed- and Rotary-wing aircraft. PAG has MRO and manufacturing capabilities in four MRO segments – Avionics, Components, Engines and Manufacturing/DER Services. PAG is dedicated to keeping mission critical, business, military, and defense operators in the air.

Call us now: 405.455.7720

Expertise

As the OEM of CeralUSA Engineered Coatings, CeralUSA certifies QCS as uniquely qualified to apply these coatings to your parts. The experienced team at QCS will help your bottom line by improving turn-time with competitive pricing.

Options

QCS understands the frustration MROs face when forced to send parts out to a sole source provider, or when making the business decision to bring coatings in-house, which can take significant investments in capital equipment and personnel training for very little profit margin. QCS was established to give you options, increasing competition and ultimately saving you money.

FAA Approved Processes

OEM	Process	Description
Pratt & Whitney	SPOP 141	Application of PWA 36595 Coating
Pratt & Whitney	SPOP 144	Coating Touch-up and Repair
Pratt & Whitney	SPOP 147	Application of Inorganic Coatings
Pratt & Whitney	SPOP 150	Anti-Gallant
Pratt & Whitney	SPOP 160	Anti-Gallant
Pratt & Whitney	SPOP 162	Application of PWA 110 Coatings
Pratt & Whitney	SPOP 164	Application of PWA 595 Coatings
Pratt & Whitney	SPOP 19	Plastic Media Blast
Pratt & Whitney	SPOP 203	Coating Strip
Pratt & Whitney	SPOP 208	Solvent Degreasing
Pratt & Whitney	SPOP 209	Aqueous Degreasing
Pratt & Whitney	SPOP 21	Cadmium Strip
Pratt & Whitney	SPOP 218	Dry Abrasive Grit Blast
Pratt & Whitney	SPOP 25	Nickel Cadmium Strip
Pratt & Whitney	SPOP 258	Coating Strip
Pratt & Whitney	SPOP 500	Glass Bead Peen
Pratt & Whitney	PWA 110	Application of Inorganic Coatings
Pratt & Whitney	PWA 36252	Coating, Aluminum, Heat & Corrosion Resistant
Pratt & Whitney Canada	CPW420	Application of Inorganic Coatings

About Ceral USA

Capabilities

Qualified Coating Services has invested the time, energy and capital to procure the best equipment on the market, ensuring consistently qualified coatings, every time. With its infrastructure, equipment and personnel, QCS offers the following capabilities:

Stripping
Cleaning
Degreasing
Heat Treatment
Abrasive Blasting
Coating Application
Surface Finishing
Coating Evaluation
Cadmium Stripping
Glass Bead Blasting
Coating Development
Coating Application Development

Our FAA approved capabilities are maintained via an internal “Capabilities List” per 14 CFR 14.215. From a practical point of view that means that we can add additional articles to our list in short order. Please check with us if you have an aircraft article that you’d like coated that isn’t presently on our list.

Products

Aluminum Ceramic Coatings
Used primarily to protect against corrosion and erosion on steel parts operating up to 1100°F, CeralUSA’s Aluminum Ceramic Coatings provide a barrier between the substrate and the environment and can be made conductive to provide galvanic and sacrificial protection. They are resistant to hydraulic fluids, fuel and hot water, thermal shock and impact damage, and can be applied using conventional spray, dip and brush techniques.

Ceral 66XL | Product Brochure | MSDS | Tech Bulletin
Our revolutionary new completely chrome-free, non-hazardous aluminum silicate coating passes the most stringent OEM specifications.

Ceral® 34 aka Ceral® 34SC | Product Brochure | MSDS | Tech Bulletin
Our most popular product, low-chrome Ceral 34 is proven to perform better than or equal to competitive products and is approved by multiple OEMs. NSN 8030-01-571-1611 (6850-01-571-1611)

Ceral® 114 | MSDS | Tech Bulletin
A predecessor of Ceral 34, low-chrome Ceral 114 is approved by multiple OEMs.

Top Coats and Sealers
CeralUSA’s Top Coats and Sealers are designed to improve corrosion resistance, surface finish, and longevity of CeralUSA’s Aluminum Ceramic Coatings. Versatility is an added bonus, as these coatings are available in a quick release variety as well as in a wide array of colors.

Ceral® 50 | Product Brochure | MSDS | Tech Bulletin
Zero hex-chrome Ceral 50, when used as a top coat for Ceral 34, has been proven to perform equal to or better than competitive products and is approved by multiple OEMs. Available with PTFE and/or Pigment. NSN 8030-01-571-1607 (6850-01-571-1607)

Ceral® VPW 350/1 | MSDS | Tech Bulletin
Ceral VPW 350/1 was designed as a top coat for Ceral 114 and is approved by multiple OEMs.

Diffusion Coating Products
Used primarily to protect against corrosion and erosion on parts operating up to 1830°F, CeralUSA’s diffusion coating products are the environmentally friendly, more cost effective replacement for antiquated processes such as pack cementation, chemical vapor deposition, plasma spray, electron beam evaporation and electroplating. Our diffusion slurries are produced in plain and silicon modified aluminide formulations.

LSR® H2O Sialoy 2-Part | MSDS | Tech Bulletin
The diffused LSR H2O Sialoy coating provides the same protection as the original LSR Sialoy however it’s built on a water-based binder. Some customers prefer this water-based binder as it makes LSR H2O a drop-in replacement for the legacy diffusion coatings they’re accustomed to. LSR-H2O contains neither hazardous ingredients nor does it produce hazardous by-products as a result of being diffused. Now furnished in two parts for local mixing. NSN 8030-01-593-7078

Ceral® 10 Green
Ceral 10 Green is a solvent based slurry diffusion aluminide coating specifically designed to protect superalloys. Ceral 10 Green provides excellent protection against erosion, high temperature oxidation as well as high temperature and low temperature corrosion. Ceral 10 Green is entirely chrome-free. Approved to P&W PWA 596-3.

Ceral® 10
Ceral 10 is a silicon doped slurry diffusion aluminide coating specifically designed to protect superalloys. Ceral 10 provides excellent protection against erosion, high temperature oxidation as well as high temperature and low temperature corrosion. Ceral 10 contains a small amount of Cr6+.

Equipment
CeralUSA promotes the use of proper equipment for the storage, preparation, application and finishing of our engineered coatings.

CeralUSA Rolling Machine | Product Brochure
This light weight, low profile roller unit was designed as a compact, space saving instrument which may be used continuously to keep product solids in suspension.
